ETCD 服务发现

在微服务中各个服务都是无状态的，不会在配置中写死上下游的访问地址，所以需要有一个地方去维护各个节点的信息。

服务起来的时候会去注册中心拉取其他服务的节点信息，并且把自己的信息推送到注册中心。

当有运行的服务下线或者出现问题的时候，把自己从配置中心摘除，或者配置中心来检测服务状态（心跳、健康检查的协议）来摘除服务。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
package main

import (
    "encoding/json"
    "fmt"
    "github.com/coreos/etcd/clientv3"
    "context"
    "log"
)

type Discovery struct {
    cli       *clientv3.Client
    info      *NodeInfo
    nodes     *NodesManager
}

func NewDiscovery(info *NodeInfo, conf clientv3.Config, mgr *NodesManager) (dis *Discovery, err error) {
    d := &Discovery{}
    d.info = info
    if mgr == nil {
        return nil, fmt.Errorf("[Discovery] mgr == nil")
    }
    d.nodes = mgr
    d.cli, err = clientv3.New(conf)
    return d, err
}

func (d *Discovery) pull() {
    kv := clientv3.NewKV(d.cli)
    resp, err := kv.Get(context.TODO(), "discovery/", clientv3.WithPrefix())
    if err != nil {
        log.Fatalf("[Discovery] kv.Get err:%+v", err)
        return
    }
    for _, v := range resp.Kvs{
        node := &NodeInfo{}
        err = json.Unmarshal(v.Value, node)
        if err != nil {
            log.Fatalf("[Discovery] json.Unmarshal err:%+v", err)
            continue
        }
        d.nodes.AddNode(node)
        log.Printf("[Discovery] pull node:%+v", node)
    }
}

func (d *Discovery) watch() {
    watcher := clientv3.NewWatcher(d.cli)
    watchChan := watcher.Watch(context.TODO(), "discovery", clientv3.WithPrefix())
    for {
        select {
        case resp := <-watchChan:
            d.watchEvent(resp.Events)
        }
    }
}

func (d *Discovery) watchEvent(evs []*clientv3.Event) {
    for _, ev := range evs{
        switch ev.Type{
        case clientv3.EventTypePut:
            node := &NodeInfo{}
            err := json.Unmarshal(ev.Kv.Value, node)
            if err != nil {
                log.Fatalf("[Discovery] json.Unmarshal err:%+v", err)
                continue
            }
            d.nodes.AddNode(node)
            log.Printf(fmt.Sprintf("[Discovery] new node:%s",string(ev.Kv.Value)))
        case clientv3.EventTypeDelete:
            d.nodes.DelNode(string(ev.Kv.Key))
            log.Printf(fmt.Sprintf("[Discovery] del node:%s data:%s",string(ev.Kv.Key),string(ev.Kv.Value)))
        }
    }
}

服务注册

在etcd中服务的注册使用租约（lease）来实现，设置租约的时候按需求设置租约的时间（ttl），类似redis中的EXPIRE key，再把服务自身的节点等信息写到对应的key中。然后定时去调用KeepAliveOnce来保持租约，如果在期间KeepAliveOnce的消息丢失或者延迟大于这个租约的ttl则etcd中将会把这个节点的信息删除，恢复正常时重新发起租约流程。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100


package main

import (
    "encoding/json"
    "fmt"
    "github.com/coreos/etcd/clientv3"
    "github.com/coreos/etcd/etcdserver/api/v3rpc/rpctypes"
    "github.com/pkg/errors"
    "log"
    "time"
    "context"
)

const (
    _ttl = 10
)


type Register struct {
    cli       *clientv3.Client
    leaseId   clientv3.LeaseID
    lease     clientv3.Lease
    info      *NodeInfo
    closeChan chan error
}

func NewRegister(info *NodeInfo, conf clientv3.Config) (reg *Register, err error) {
    r := &Register{}
    r.closeChan = make(chan error)
    r.info = info
    r.cli, err = clientv3.New(conf)
    return r, err
}


func (r *Register) Run() {
    dur := time.Duration(time.Second)
    timer := time.NewTicker(dur)
    r.register()
    for {
        select {
        case <-timer.C:
            r.keepAlive()
        case <-r.closeChan:
            goto EXIT
        }
    }
EXIT:
    log.Printf("[Register] Run exit...")
}

func (r *Register) Stop() {
    r.revoke()
    close(r.closeChan)
}

func (r *Register) register() (err error) {
    r.leaseId = 0
    kv := clientv3.NewKV(r.cli)
    r.lease = clientv3.NewLease(r.cli)
    leaseResp, err := r.lease.Grant(context.TODO(), _ttl)
    if err != nil {
        err = errors.Wrapf(err, "[Register] register Grant err")
        return
    }
    data, err := json.Marshal(r.info)
    _, err = kv.Put(context.TODO(), r.info.UniqueId, string(data), clientv3.WithLease(leaseResp.ID))
    if err != nil {
        err = errors.Wrapf(err, "[Register] register kv.Put err %s-%+v", r.info.Name, string(data))
        return
    }
    r.leaseId = leaseResp.ID
    return
}

func (r *Register) keepAlive() (err error) {
    _, err = r.lease.KeepAliveOnce(context.TODO(), r.leaseId)
    if err != nil {
        // 租约丢失，重新注册
        if err == rpctypes.ErrLeaseNotFound {
            r.register()
            err = nil
        }
        err = errors.Wrapf(err, "[Register] keepAlive err")
    }
    log.Printf(fmt.Sprintf("[Register] keepalive... leaseId:%+v", r.leaseId))
    return err
}

func(r *Register) revoke() (err error) {
    _, err = r.cli.Revoke(context.TODO(), r.leaseId)
    if err != nil {
        err = errors.Wrapf(err, "[Register] revoke err")
        return
    }
    log.Printf(fmt.Sprintf("[Register] revoke node:%+v", r.leaseId))
    return
}

节点管理

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
package main

import (
    "log"
    "math/rand"
    "strings"
    "sync"
)

type NodeInfo struct {
    Addr     string
    Name     string
    UniqueId string
}

type NodesManager struct {
    sync.RWMutex
    // <name,<id,node>>
    nodes map[string]map[string]*NodeInfo
}

func NewNodeManager() (m *NodesManager){
    return &NodesManager{
        nodes: map[string]map[string]*NodeInfo{},
    }
}

func (n *NodesManager) AddNode(node *NodeInfo) {
    if node == nil {
        return
    }
    n.Lock()
    defer n.Unlock()
    if _, exist := n.nodes[node.Name]; !exist {
        n.nodes[node.Name] = map[string]*NodeInfo{}
    }
    n.nodes[node.Name][node.UniqueId] = node
}

func (n *NodesManager) DelNode(id string) {
    sli := strings.Split(id,"/")
    name := sli[len(sli)-2]
    n.Lock()
    defer n.Unlock()
    if _, exist := n.nodes[name]; exist {
        delete(n.nodes[name], id)
    }
}

func (n *NodesManager) Pick(name string) *NodeInfo {
    n.RLock()
    defer n.RUnlock()
    if nodes, exist := n.nodes[name]; !exist {
        return nil
    } else {
        // 纯随机取节点
        idx := rand.Intn(len(nodes))
        for _, v := range nodes {
            if idx == 0 {
                return v
            }
            idx--
        }
    }
    return nil
}

func (n *NodesManager) Dump () {
    for k, v := range n.nodes {
        for kk, vv := range v {
            log.Printf("[NodesManager] Name:%s Id:%s Node:%+v", k, kk, vv)
        }
    }

}

测试效果

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
package main

import (
    "github.com/coreos/etcd/clientv3"
    "log"
    "time"
)

func main() {

    nodes := NewNodeManager()
    dis, _ := NewDiscovery(&NodeInfo{
        Name: "server name/aaaa",
        Addr: "127.0.0.1:8888",
    }, clientv3.Config{
        Endpoints:   []string{"tx.cxc233.com:8888"},
        DialTimeout: 5 * time.Second,
    }, nodes)

    reg, _ := NewRegister(&NodeInfo{
        Name: "testsvr",
        Addr: "127.0.0.1:8888",
        UniqueId: "discovery/testsvr/instance_id/aaabbbccc",
    }, clientv3.Config{
        Endpoints:   []string{"tx.cxc233.com:8888"},
        DialTimeout: 5 * time.Second,
    })

    reg2, _ := NewRegister(&NodeInfo{
        Name: "testsvr",
        Addr: "127.0.0.1:8888",
        UniqueId: "discovery/testsvr/instance_id/testqqqqq",
    }, clientv3.Config{
        Endpoints:   []string{"tx.cxc233.com:8888"},
        DialTimeout: 5 * time.Second,
    })

    go reg.Run()
    time.Sleep(time.Second * 2)
    dis.pull()
    go dis.watch()
    time.Sleep(time.Second * 1)
    go reg2.Run()
    time.Sleep(time.Second * 1)
    nodes.Dump()
    log.Printf("[Main] nodes pick:%+v",nodes.Pick("testsvr"))
    time.Sleep(time.Second * 5)
}

运行结果

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
2020-10-18 22:36:39.102233 I | [Register] keepalive... leaseId:7587849142468224212
2020-10-18 22:36:40.100365 I | [Register] keepalive... leaseId:7587849142468224212
2020-10-18 22:36:40.100365 I | [Discovery] pull node:&{Addr:127.0.0.1:8888 Name:testsvr UniqueId:discovery/testsvr/instance_id/aaabbbccc}
2020-10-18 22:36:41.100389 I | [Register] keepalive... leaseId:7587849142468224212
2020-10-18 22:36:41.143304 I | [Discovery] new node:{"Addr":"127.0.0.1:8888","Name":"testsvr","UniqueId":"discovery/testsvr/instance_id/testqqqqq"}
2020-10-18 22:36:42.097662 I | [Register] keepalive... leaseId:7587849142468224212
2020-10-18 22:36:42.100819 I | [NodesManager] Name:testsvr Id:discovery/testsvr/instance_id/aaabbbccc Node:&{Addr:127.0.0.1:8888 Name:testsvr UniqueId:discovery/testsvr/instance_id/aaabbbccc}
2020-10-18 22:36:42.100819 I | [NodesManager] Name:testsvr Id:discovery/testsvr/instance_id/testqqqqq Node:&{Addr:127.0.0.1:8888 Name:testsvr UniqueId:discovery/testsvr/instance_id/testqqqqq}
2020-10-18 22:36:42.100819 I | [Main] nodes pick:&{Addr:127.0.0.1:8888 Name:testsvr UniqueId:discovery/testsvr/instance_id/testqqqqq}
2020-10-18 22:36:42.107588 I | [Register] keepalive... leaseId:7587849142468224216
2020-10-18 22:36:43.091650 I | [Register] keepalive... leaseId:7587849142468224212
2020-10-18 22:36:43.109634 I | [Register] keepalive... leaseId:7587849142468224216
2020-10-18 22:36:44.093966 I | [Register] keepalive... leaseId:7587849142468224212
2020-10-18 22:36:44.108130 I | [Register] keepalive... leaseId:7587849142468224216
2020-10-18 22:36:45.093075 I | [Register] keepalive... leaseId:7587849142468224212
2020-10-18 22:36:45.114071 I | [Register] keepalive... leaseId:7587849142468224216
2020-10-18 22:36:46.107634 I | [Register] keepalive... leaseId:7587849142468224212
2020-10-18 22:36:46.114016 I | [Register] keepalive... leaseId:7587849142468224216
2020-10-18 22:36:47.091863 I | [Register] keepalive... leaseId:7587849142468224212

Go Dockerfile 构建

FROM golang:1.15

docker有一个基本镜像叫做scratch，它是一个空的镜像，在临时基础镜像上运行的应用程序只能访问内核

由于需要依赖cgo，所以我们使用scratch无法满足需求，我们需要另外一个运行时基础镜像alpine，看下dockerhub官方的介绍，它也仅仅只有5MB大小。

生成镜像，使用当前文件构建一个镜像

1
docker build -t changcrazy/service.doumi.com:v1  .

启动一个容器

1
docker run -d centos_nginx:v1 /usr/local/nginx/sbin/nginx -g "daemon off;"
阅读全文 »

Yar (Yet Another RPC Framework) 一个rpc框架

Yar 是一个轻量级, 高效的RPC框架, 它提供了一种简单方法来让PHP项目之间可以互相远程调用对方的本地方法. 并且Yar也提供了并行调用的能力. 可以支持同时调用多个远程服务的方法.

阅读全文 »

常见的并发模型:

进程与线程（apache） C10K 问题

  • nginx,nodejs 异步非阻塞 复杂度高
  • golang ，lua，erlang 协程方式

golang 中使用goroutine 实现并发的，channels 在多个goroutine 间的数据同步和通信，select在多个channels中选择数据的读取和写入。

并发与并行

并发： 指同一时刻，系统通过调度，来回切换交替的运行多个任务，“看起来”是同时进行

并行： 指同一个时刻，两个任务”真正的“同时进行

讲解地址 搬运废书问题

将复杂的任务拆分，通过goroutine去并发执行。

Coroutine

  • 指针，& 取地址。

修改结构体的变量内容的时候，方法传入的结构体变量参数需要使用指针，也就是结构体的地址

阅读全文 »

Go Cheat Sheet

一个整理了很多语言的cs

GO cheatsheet

GO cheatsheet

类库和框架等

Index

  1. Basic Syntax
  2. Operators
  3. Declarations
  4. Functions
  5. Built-in Types
  6. Type Conversions
  7. Packages
  8. Control structures
  9. Arrays, Slices, Ranges
  10. Maps
  11. Structs
  12. Pointers
  13. Interfaces
  14. Embedding
  15. Errors
  16. Concurrency
  17. Printing
  18. Reflection
  19. Snippets
阅读全文 »

Google 搜索技巧

  1. 使用“本尊”

最好使用 http://www.google.com/ncr NCR: No Country Redirection，而不是http://www.google.com.hk；有时，直接输入http://www.google.com也会被自动转到“本地Google”，比如，我用日本的 VPN，浏览器就会把我转到http://www.google.co.jp……

  1. 优先使用英文关键字搜索

这是个好习惯。别说不会英文，不会就学，没那么难。

  1. 基本技巧

Google 搜索引擎也许是世界上最简单的应用界面，只有一个输入框和一个按钮。然而，用好它还是需要花点时间去学习的。Google 有帮助文档，还专门设计了个学习网站 A Google A Day

a）加号

在 Google 的输入框里，所有的空格都被 Google 理解为加号+。如果你输入的是 purpose of education那么 Google 返回的文章里既有“purpose”存在，也有“education”存在，但不一定有“purpose of education”存在。另外，过分常用的、单独存在没有意义的词汇往往被忽略掉，比如冠词“a”、“the”；介词“of”、“in”、“on”、“at”、“to”；连词“and”、“or”、“but”；从属连词“that”、“which”、“when”；代词“my”、“his”、“them”等等。

阅读全文 »

快速安装：

yum install go

源码安装最新版

git clone https://github.com/golang/go.gitcd go/git checkout 1.13版本cd srcall.bash

成功后就将go/bin/go 添加到环境变量即可。
环境变量

goexport GOPATH=$HOME/www/go:$HOME/www/baxian/baxian_sea/doc/data/tokumxexport GOBIN=$HOME/www/bin

阅读全文 »
